How To Install Zabbix 5.0 On Ubuntu 20.04 May 17, 2020 Raj 3 min read CONTENTS Install Zabbix 5.0 On Ubuntu 20.04 System Requirements Configure Zabbix repository Install Zabbix Server Timezone Create Database Update Zabbix Configuration Setup Zabbix via Web Installer Access Zabbix Conclusion SHARE THIS DOCUMENT IS ALSO AVAILABLE FOR CentOS 8 CentOS 7 Debian 10 Debian 9 Ubuntu 18.04 Ubuntu 16.04 Zabbix is an open-source enterprise-class monitoring tool for servers, network devices, and applications. Zabbix uses the agent installed on remote hosts to collect the system metrics. It can also monitor standard services such as SMTP or HTTP services without having a client on the remote host. Additionally, Zabbix supports host monitoring via SNMP, TCP, and ICMP checks, as well as over IPMI, JMX, SSH, and telnet. Zabbix can send you with real-time alert notification via SMS, E-mail, alert scripts, and webhook. Zabbix is released under the GPL license v2. Here, we will see how to install Zabbix Server Ubuntu 20.04. Install Zabbix 5.0 On Ubuntu 20.04 System Requirements Zabbix requires at least 128MB of RAM and 256MB of HDD space. However, the amount of memory or disk depends on the number of hosts and parameters are being monitored. Ubuntu machine with a 2GB of RAM and 2GB of disk space would be sufficient to monitor 500 hosts. Configure Zabbix repository Zabbix LLC provides Zabbix packages over an official repository for Ubuntu 20.04. So, set up the Zabbix repository on the system. wget https://repo.zabbix.com/zabbix/5.0/ubuntu/pool/main/z/zabbix-release/zabbix-release_5.0-1+focal_all.deb sudo dpkg -i zabbix-release_5.0-1+focal_all.deb Install Zabbix Server Use the apt command to install the Zabbix server along with MariaDB on your system. sudo apt update sudo apt -y install zabbix-server-mysql zabbix-frontend-php zabbix-agent zabbix-apache-conf Timezone Edit the Zabbix configuration file to update it with the correct timezone based on your location. sudo nano /etc/zabbix/apache.conf Update the below line with your timezone. Visit the link for supported timezones. <IfModule mod_php7.c> ... ... php_value date.timezone America/New_York ... ... </IfModule> Create Database Login to the MariaDB server and create a database for the Zabbix installation. sudo mysql -u root -p Here, I assume the following: DBName: zabbix DBUser: zabbixuser DBPassword: password create database zabbix character set utf8 collate utf8_bin; grant all privileges on zabbix.* to zabbixuser@localhost identified by 'password'; quit; Import the initial schema into the created database. cd /usr/share/doc/zabbix-server-mysql zcat create.sql.gz | mysql -u zabbixuser -p zabbix Update Zabbix Configuration Edit the zabbix_server.conf file to update the database details. sudo nano /etc/zabbix/zabbix_server.conf Ensure the database details are entered properly. DBHost=localhost DBName=zabbix DBUser=zabbixuser DBPassword=password Restart all the services. sudo systemctl restart zabbix-server zabbix-agent apache2 Enable the services to start automatically on system reboot. sudo systemctl enable zabbix-server zabbix-agent apache2 Setup Zabbix via Web Installer Open a web browser and point it to the following URL. http://your-ip-add-ress/zabbix/ Click Next Step on Zabbix welcome page. Zabbix 5.0 Welcome Screen This page will show the result of the pre-requisites check for Zabbix Installation. If there are any issues, those need to be fixed before proceeding to the next step. If everything is OK, click the Next Step. Zabbix Installation Pre Checks Enter the Zabbix database name, DB user, and password, and then click Next Step. Database Information Mention the Zabbix server details, port number, and the name for the Zabbix installation. Then, click Next Step. Zabbix Server Details You will get a pre-installation summary like below. Click Next Step to go to the next page. Zabbix Pre-Installation Summary Now, you have completed the installation of Zabbix. Click Finish. Zabbix Installation Completed Once after you clicked the Finish button, the installer will redirect you to the Zabbix Login Page. Access Zabbix Open a web browser and point it to the following URL. http://your-ip-add-ress/zabbix/ Log in to Zabbix Server with the default username and password. Username: Admin Password: zabbix Username is case sensitive. Zabbix Login Page Zabbix Dashboard: Zabbix 5.0 Dashboard Conclusion That’s All. Now, you can proceed to install Zabbix Agent on client systems and then add client machines to the Zabbix server for monitoring. ubuntu-20.04 monitoring-tools zabbix Prev Post How To Install WordPress With Nginx On Ubuntu 20.04 Next Post How To Update Ubuntu 20.04 LTS RELATED POSTS How To Install Nagios On Ubuntu 20.04 How To Upgrade To Ubuntu 20.04 From Ubuntu 18.04 / Ubuntu 19.10 [Detailed Guide] How To Install WordPress With Nginx On Ubuntu 20.04 How To Install Node.js on Ubuntu 20.04 How To Install Atom Editor On Ubuntu 20.04 How To Setup Let's Encrypt SSL Certificate With Nginx on Ubuntu 20.04 Please enable JavaScript to view the comments powered by Disqus. comments powered by Disqus RECENT POSTS How To Install VirtualBox On Linux Mint 20 How To Backup and Restore Ubuntu & Linux Mint With Timeshift How To Upgrade To Linux Mint 20 From Linux Mint 19 [Detailed Guide] How To Install KVM On Ubuntu 20.04 / Linux Mint 20 How To Install Plex Media Server On Ubuntu 20.04 / Linux Mint 20 How To Install Android Studio on Ubuntu 20.04 TOP POSTS Install xrdp on CentOS 7 / RHEL 7 Install Gnome GUI on CentOS 7 / RHEL 7 Change default network name (ens33) to old “eth0” on Ubuntu… Install μTorrent (uTorrent) on Ubuntu 14.04 How To Configure High-Availability Cluster on CentOS 7 /… How To Install and Configure VNC Server in CentOS 7 / RHEL 7
